Technical Specification of Water Tank Radiator OE 8602421

The water tank radiator with OE number 8602421 is a heavy-duty cooling component specifically designed for CASE and New Holland wheel loaders, widely applicable to multiple models. It is compatible with CASE 621D/E/F/G, 721D/E/F/G, 821F/G and New Holland W130B/C, W170B/C, W190C loaders, perfectly matching their engine cooling needs and ensuring stable operation under continuous heavy-duty construction conditions.

Constructed with full heavy-duty aluminum, including aluminum tanks and a plate-fin core without a steel frame, this radiator weighs approximately 200 pounds (90.7 kg) and has a working pressure of 2.0 MPa (20 bar). It has passed ISO9001 and TS16949 certifications, with a 12-month warranty for aftermarket parts, and its price range is $600–$1,200 for new replacements. Its cross-reference numbers include 47775033, 84232364, and 87740232, facilitating spare part matching.

In terms of dimensions, the overall height (including brackets) is about 50 inches (1270 mm), width 40 inches (1016 mm), and depth 18 inches (457 mm). The core, a key part for heat dissipation, has a height of 28.625 inches (727 mm), width of 22.375 inches (568 mm), and thickness of 3.875 inches (98 mm). The inlet (44.5 mm) is on the right top, the outlet (63.5 mm) on the left bottom, and the filler neck is top-mounted, with OEM-matched brackets for direct installation.
